LIFTIT Chain Pulley Block 1 Ton Hoist

home
LIFTIT Chain Pulley Block 1 Ton Hoist
LIFTIT Chain Pulley Block 1 Ton Hoist
Price And Quantity
  • Piece/Pieces
  • 1
  • Piece/Pieces
  • 6800 INR
    Product Specifications
    • Yellow
    • 12.50 Kilograms (kg)
    • Suitable for lifting, pulling, and positioning heavy loads in workshops, warehouses, and construction sites
    • 1 ton Chain Pulley Block
    • New
    • 1 Tonne
    • 1 Tonne
    • 3 Meter (m)
    • Manual
    Product Description

    LIFTIT Chain Pulley Block 1 Ton Hoist


    LIFTIT BRAND LOW EFFORT AND HIGH SPEED CHAIN PULLEY BLOCKS


    Reduces and Minimises the Lifting forces upto almost 35% and makes the Chain Blocks work on higher speeds,


    These Chain Blocks are Made from the Highest Quality Hardened Triple Spur Gears, Grade 80 Alloy Steel Load Chains and Zinc Plated Hand Chains.


    Special Features of LIFTIT BRAND LOW EFFORT AND HIGH SPEED CHAIN PULLEY BLOCKS


    MADE BY SPECIAL NEW TECHNOLOGY OF LOW EFFORT and HIGH SPEED MECHANISM


    Meets all the Required world Standards for Lifting Chain Blocks


    Light weight and High Strength Grade 80 Alloy Steel Chain


    Compact Design Makes it Eligible for Low Head Room applications.


    Reinforced Double Pawl Brake System and Large Dia Pawl Springs makes higher braking efficiency.


    Open Frame design makes it easy for maintenance and periodic inspections,

    Technical Specification

    Model                                                       1 Ton

    Capacity                                                   1 Ton

    Standing Lifting Height                             3 Meter and for extra length                                                                         contact us

    Running test load                                     1500 Kg

    Effort required to lift max

    Load                                                         309 N

    Load Chain Dia                                         6 x 18 mm

    Hand Chain Dia                                        5 x 22.2 mm

    Net - Gross Weight                                   11.30 - 12.50 Kg

    Packing Size                                             29 x 22 x 18 CM

    Extra weight meter of extra

    lift                                                               1.62 Kg

    Dimension

    A = 140 MM
    B = 158 MM
    C = 317 MM
    D = 35.5 MM
    K = 28 MM




    Trade Information
    • Surat
    • Cash in Advance (CID) Cash Against Delivery (CAD) Cash Advance (CA) Cheque
    • 10 Per Day
    • 1 Days
    • If order is confirmed we will reimburse the sample cost
    • Box packing
    • Asia Australia Central America North America South America Western Europe Middle East Africa
    • All India
    • Test Certificate
